Adaptive Component – Post Tension Reinforcing Bar Family

28 February 2013 · Luke Johnson

Cool post by Håvard Vasshaug, where he describes how he modelled and controlled a post tensioned reinforcing bar using a Revit Adaptive Component. Even better, you can download the family.

Image unavailable in the preserved source

Discussion

1 archived comments. New comments are not enabled.

Max Kotsar 2013-02-28 18:09:04

Hi, Luke. PT rebars modeling via adaptive components is a good idea. But for this purpose I usually use PT tendons family based on structural framing template . It not only creates the tendons, but also sends an analytical model with all loads from post tension in RSA for further analysis. You can read more on my blog: Perfect Project
